FAQ

1. What is the power of R1 and R1 PRO?

R1 is a 10W, 450nm blue diode laser engraving machine.
R1 PRO is a 20W, 450nm blue diode laser engraving machine.

2. What is the focal length of R1 and R1 PRO?

R1 and R1 PRO have a focal length of
16cm/160mm.

3. What is the engraving area of R1 and R1 PRO?

100*100mm/100*600mm (with Rotary Roller G1).

4. How fast can the R1 and R1 PRO engrave?

R1 and R1 PRO can engrave at speeds of 2mm/s–2000mm/s.

5. What materials can R1 and R1 PRO engrave on?

R1 and R1 PRO can engrave on a wide range of materials, including paper, wood, leather, MDF, 304 stainless steel, dark opaque acrylic, bamboo, fabric, dark glass, ceramic, jade, marble, slate, cement, brick, painted metal parts, anodized metal, coated metal, stone, and more.

6. What APP can I use to connect R1 and R1 PRO?

Please scan the QR code in the user manual, visit the official website, or search for Raymoto on Huawei AppGallery, Google Play Store, Apple App Store, and other major app stores to download the app (requires iOS 16.0 or later or Android 10.0 or later).

7. Are R1 and R1 PRO compatible with LightBurn?

Yes. R1 and R1 PRO are compatible with LightBurn. For detailed information, please refer to the LightBurn Compatibility Guide.

8. What accessories are compatible with R1 and R1 PRO?

R1 and R1 PRO can be used with a wide range of accessories, including the Multi-Function Electric Roller, Protective Cover, RM Power Bank, L-shaped Positioning Guide, RM Air Purifier, RM Foot Switch, Safety Goggles, and more.

9. Are R1 and R1 PRO Class 1 laser products?

Yes. Both R1 and R1 PRO are Class 1 laser products.

Under normal operating conditions, the laser operates inside the protective enclosure, ensuring that accessible laser radiation remains within Class 1 safety limits.

For added safety, both the protective enclosure and base plate are equipped with safety interlock switches. If the enclosure or base plate is opened during operation, the laser will immediately stop emitting to help ensure user safety.

10. What safety certifications does R1 and R1 PRO have?

R1 and R1 PRO have IEC 60825, CE, FCC, RoHS, UKCA, and FDA Registered certifications.

11. What is the warranty period for R1 and R1 PRO?

We provide a one-year warranty for R1 and R1 PRO, starting from the date you receive the product.

→ Learn more about the Raymoto Warranty Policy.

Still have questions? Get in touch.

1. What is the power of A1?

A1 is a 7W, 450nm blue diode laser engraving machine.

2. What is the focal length of A1?

A1 have a focal length of
10.8cm/108mm.

3. What is the engraving area of A1?

75*75mm.

4. How fast can the A1 engrave?

A1 can engrave at speeds of 5mm/s–500mm/s.

5. What materials can A1 engrave on?

A1 can engrave on a wide range of materials, including paper, wood, leather, MDF, 304 stainless steel, dark opaque acrylic, bamboo, fabric, dark glass, ceramic, jade, marble, slate, cement, brick, painted metal parts, anodized metal, coated metal, stone, and more.

6. What APP can I use to connect A1?

Please scan the QR code in the user manual, visit the official website, or search for Raymoto on Huawei AppGallery, Google Play Store, Apple App Store, and other major app stores to download the app (requires iOS 16.0 or later or Android 10.0 or later).

7. Are A1 compatible with LightBurn?

 Sorry, A1 isn't compatible with lightburn currently.

8. What accessories are compatible with A1?

A1 can be used with a wide range of accessories, including the Battery Handle, Protective Shield, Air Purifier, Tripod, Safety Goggles.

9. Are A1 Class 1 laser products?

The laser safety classification depends on the A1 version:

  • A1 Enclosed: Class 1
  • A1 Standard: Class 4
  • A1 Portable Kit: Class 4
  • A1 Basic: Class 4

10. What is the warranty period for A1?

We provide a one-year warranty for A1, starting from the date you receive the product.

→ Learn more about the Raymoto Warranty Policy.

Still have questions? Get in touch.
